TechniSat DIGITRADIO 10 IR User Manual

113
DE
EN
NL
FR
> In the next step you can specify whether the DIGITRADIO 10 IR should remain
connected to the Internet when on standby. This can, for example, be useful
for App control (Spotify Connect). Power consumption is, however, increased
by using the standby mode.
> The network wizard then starts and you can set up an Internet connection.
Use the / and OK buons to select the WiFi network you recognise and
enter the relevant password using the displayed keyboard (skip WPS). Then
select
and press the OK buon. If the password entered is correct a
connection to the network is now established. The signal bar
in the status
bar of the display indicates whether the connection has been established. To
cancel the entry, select and press the OK buon. If you make a typing
error you can delete the last leer entered using .
While the virtual keyboard is displayed, you can use / on the remote
control to navigate. The / buons move the highlight upwards and
downwards, the / buons move the highlight to the right and le.

TechniSat DIGITRADIO 10 IR Specifications

General

Radio type	Internet
Tuner type	Digital
FM band range	87.5 - 108 MHz
DAB band range	174 - 240 MHz
Supported radio bands	DAB+, FM
Preset stations quantity	60
Equalizer	Yes
RMS rated power	- W
Built-in speaker(s)	No
Display type	TFT
Display diagonal	2.8 \
Display resolution	240 x 320 pixels
Wi-Fi standards	802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n)
Bluetooth version	4.1
Coloration	Monochromatic
Thermometer	-
Antenna type	External
Product color	Black, Silver
Internet radio services supported	Spotify
On Screen Display (OSD) languages	DAN, DEU, DUT, ENG, FIN, FRE, ITA, NOR, POL, POR, SWE
Power source	AC/DC
AC input voltage	230 V
DC input voltage	5 V
AC input frequency	50 Hz
Power consumption (standby)	0.72 W
Power consumption (typical)	1.4 W
Clock mode	24h
Operating temperature (T-T)	5 - 35 °C
Operating relative humidity (H-H)	5 - 90 %

Weight and Dimensions

Width	- mm
