TechniSat DIGITRADIO 10 IR User Manual

151
DE
EN
NL
FR
16.7 SW update
The SW update option is used to update the device soware and is only intended for
use when servicing.
16.8 Initial set-up
Here the initial set-up wizard can be accessed again. For more details, see Section „8
Ersteinrichtung“ auf Seite 112.
16.9 Data protection
Under this option you can find the data protection information.
17 Cleaning
To prevent the risk of electric shock, you must not clean the device using a wet
cloth or under running water. Prior to cleaning, pull out the mains plug and
switch o the device.
You must not use scouring pads, scouring powder and solvents such as
alcohol or petrol.
Do not use any of the following substances: saltwater, insecticide, chlorine-
based or acidic solvents (ammonium chloride).

TechniSat DIGITRADIO 10 IR Specifications

General

Radio type	Internet
Tuner type	Digital
FM band range	87.5 - 108 MHz
DAB band range	174 - 240 MHz
Supported radio bands	DAB+, FM
Preset stations quantity	60
Equalizer	Yes
RMS rated power	- W
Built-in speaker(s)	No
Display type	TFT
Display diagonal	2.8 \
Display resolution	240 x 320 pixels
Wi-Fi standards	802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n)
Bluetooth version	4.1
Coloration	Monochromatic
Thermometer	-
Antenna type	External
Product color	Black, Silver
Internet radio services supported	Spotify
On Screen Display (OSD) languages	DAN, DEU, DUT, ENG, FIN, FRE, ITA, NOR, POL, POR, SWE
Power source	AC/DC
AC input voltage	230 V
DC input voltage	5 V
AC input frequency	50 Hz
Power consumption (standby)	0.72 W
Power consumption (typical)	1.4 W
Clock mode	24h
Operating temperature (T-T)	5 - 35 °C
Operating relative humidity (H-H)	5 - 90 %

Weight and Dimensions

Width	- mm
