TechniSat DIGITRADIO 10 IR User Manual

101
DE
EN
NL
FR
6.2 Special features of the DIGITRADIO 10 IR
The DIGITRADIO 10 IR is comprised of a DAB+/FM/Internet radio receiver having the
following functions:
- You can store up to 30 DAB+ and 30 FM stations.
- The radio receives on the FM 87.5–108 MHz (analogue) frequencies and
DAB+ 174.9 – 239.2 MHz (digital antenna), 252 - 261 MHz (digital cable).
- The device has a time and date display.
- Music playback via Bluetooth connection.
- Colour display
- Spotify Connect playback
6.3 Preparing the DIGITRADIO 10 IR for operation
6.3.1 Connect and align the dipole antenna
The number and quality of the stations to be received depend on the reception
conditions at the installation location. Excellent reception can be achieved with the
dipole antenna.
> Insert the dipole antenna into the RF IN antenna port (3). If supported by
your cable network operator, you can also receive DAB+ via the cable socket
(adapter/cable not supplied).

TechniSat DIGITRADIO 10 IR Specifications

General

Radio type	Internet
Tuner type	Digital
FM band range	87.5 - 108 MHz
DAB band range	174 - 240 MHz
Supported radio bands	DAB+, FM
Preset stations quantity	60
Equalizer	Yes
RMS rated power	- W
Built-in speaker(s)	No
Display type	TFT
Display diagonal	2.8 \
Display resolution	240 x 320 pixels
Wi-Fi standards	802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n)
Bluetooth version	4.1
Coloration	Monochromatic
Thermometer	-
Antenna type	External
Product color	Black, Silver
Internet radio services supported	Spotify
On Screen Display (OSD) languages	DAN, DEU, DUT, ENG, FIN, FRE, ITA, NOR, POL, POR, SWE
Power source	AC/DC
AC input voltage	230 V
DC input voltage	5 V
AC input frequency	50 Hz
Power consumption (standby)	0.72 W
Power consumption (typical)	1.4 W
Clock mode	24h
Operating temperature (T-T)	5 - 35 °C
Operating relative humidity (H-H)	5 - 90 %

Weight and Dimensions

Width	- mm
