16.1.1.2 Configuration via the WPS function
This establishes a direct connection to the router. Selecting and/or entering a WLAN
network
(SSID) and password is not required.
> Start the WPS function on your router as per the instruction manual.
> Then select [Use WPS via buon] to launch the connection process.
Please observe the display overlays. The connection process is generally
completed in a few seconds and the WLAN connection can be used.
Alternatively the [Use WPS via PIN] function can be used if this function is
supported by the router.
16.1.1.3 Manual configuration
> Select [Set manually] and then [Wireless] to launch manual configuration.

TechniSat DIGITRADIO 10 IR Specifications

General

Radio type	Internet
Tuner type	Digital
FM band range	87.5 - 108 MHz
DAB band range	174 - 240 MHz
Supported radio bands	DAB+, FM
Preset stations quantity	60
Equalizer	Yes
RMS rated power	- W
Built-in speaker(s)	No
Display type	TFT
Display diagonal	2.8 \
Display resolution	240 x 320 pixels
Wi-Fi standards	802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n)
Bluetooth version	4.1
Coloration	Monochromatic
Thermometer	-
Antenna type	External
Product color	Black, Silver
Internet radio services supported	Spotify
On Screen Display (OSD) languages	DAN, DEU, DUT, ENG, FIN, FRE, ITA, NOR, POL, POR, SWE
Power source	AC/DC
AC input voltage	230 V
DC input voltage	5 V
AC input frequency	50 Hz
Power consumption (standby)	0.72 W
Power consumption (typical)	1.4 W
Clock mode	24h
Operating temperature (T-T)	5 - 35 °C
Operating relative humidity (H-H)	5 - 90 %

Weight and Dimensions

Width	- mm
