TechniSat DIGITRADIO 10 IR User Manual

140
You can now choose whether to use the WPS function or whether you prefer
to enter your WLAN password manually.
> If you would like to use the WPS function, launch it on your router first as per
its instruction manual and then select [Use WPS via buon] in the network
wizard.
Please observe the display overlays. The connection process is generally
completed in a few seconds and the WLAN connection can be used.
> If you wish to enter your WLAN password manually, or if your router does not
support the WPS function, select [Skip WPS].
> Then enter your WLAN password using the virtual keyboard display and
confirm your selection with OK.
The entered password will then be verified. This process is generally
completed in a few seconds and the WLAN connection can then be used.

TechniSat DIGITRADIO 10 IR Specifications

General

Radio type	Internet
Tuner type	Digital
FM band range	87.5 - 108 MHz
DAB band range	174 - 240 MHz
Supported radio bands	DAB+, FM
Preset stations quantity	60
Equalizer	Yes
RMS rated power	- W
Built-in speaker(s)	No
Display type	TFT
Display diagonal	2.8 \
Display resolution	240 x 320 pixels
Wi-Fi standards	802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n)
Bluetooth version	4.1
Coloration	Monochromatic
Thermometer	-
Antenna type	External
Product color	Black, Silver
Internet radio services supported	Spotify
On Screen Display (OSD) languages	DAN, DEU, DUT, ENG, FIN, FRE, ITA, NOR, POL, POR, SWE
Power source	AC/DC
AC input voltage	230 V
DC input voltage	5 V
AC input frequency	50 Hz
Power consumption (standby)	0.72 W
Power consumption (typical)	1.4 W
Clock mode	24h
Operating temperature (T-T)	5 - 35 °C
Operating relative humidity (H-H)	5 - 90 %

Weight and Dimensions

Width	- mm
