RUNRACE : Service & Maintenance Manual - rev. 2.0
Page 2.12
RNIMQ-13S: Emergency button cable
CPU – Emergency button
CPU board
CN2
Signal Color Emergency
button
2 Reference Brown 1
3 NC contact Blue 2
RN-5TQ: Inverter cable
Inverter interface board – Inverter – Motor thermal cutout
Inverter interf.
board
CN1
Signal Color Inverter Motor thermal
cutout
1 Reference White PV24 -
1 Thermal cutout
reference
Red - 1
- NC thermal cutout Red 3 2
2 Start Gray 1 -
3 NC Alarm Violet AL1 -
4 Alarm reference Red AL0 -
5 Vref (0-10 Vdc) Brown 0 -
6 Vref reference Black L -
RN-14: Belt motor cable
Inverter – Belt motor
Inverter Signal Color Belt motor
U Phase U Blue U
V Phase V Black V
W Phase W Brown W
PE ground Yellow-Green Casing
RN-6: Up-down motor cable
Up-down board – Up-down motor – Limit Switches
Up-down board
CN3
Signal Color Up-down
motor
Upper
LS
Lower
LS
1 Motor power supply Brown 1 - -
2 Motor ground Blue 2 - -
3 NO upper limit White - 3 -
4 NC lower limit switch Violet - - 2
6 Limit switch ground Black - 1 1
