Technogym Skillmill GO - Page 22

CU0863: Cable A - Angle sensor
(Patch connector/Angle sensor)
Patch connector Signal Colour Angle sensor
1  Brown 1
2  White 2
3  Green 3
CU0864: Magnetic pick up cable
(Low Kit /Magnetic pick up)
Low Kit Signal Colour Magnetic pick up
1  Brown 1
2  Black 2
CU0865: TGS / NFC cable
(Patch connector/ UI board connection)
Patch connector Signal Colour UI board connection
1  Yellow 1
2  Brown 2
3  White 3
4  Green 4
CU0866: TGS / NFC cable
(Low Kit / UI board connection)
Patch connector Signal Colour Low Kit
1  Black 1
2  Brown 2
3  White 3
4  Blue 4
5  Grey 5
-  6
-  7
-  8
Skillmill
Technical Service Guide - Rev. 2.2
Page 22
