CU0867: Cable B - Angle sensor
(Patch connector/Low Kit)
Patch connector Signal Colour Low Kit
1  Brown 1
2  White 2
3  Green 3
CU0883: Cable B - Low Kit / UI board connection
(Patch connector/Patch connector)
Patch connector Signal Colour Patch connector
1  Yellow 1
2  Brown 2
3  White 3
4  Green 4
5  Grey 5
CU0884: Cable B - TGS / NFC
(Patch connector/Patch connector)
Patch connector Signal Colour Patch connector
1  Yellow 1
2  Brown 2
3  White 3
4  Green 4
