SPAZIO FORMA: Service & Maintenance manual - rev. 1.0
Page 8.3
8.3. CENTERING THE TREAD-BELT
Figure 8.3-1
1. Start the machine at a speed of 10 Km/h.
2. Observe the movement of the tread-belt,
correcting any tendency to shift to the right or
left exclusively by adjusting the screw a.
Locking down this screw favors shifting of
the belt to the right, and vice versa.
3. Gradually increase the speed to 16 km/h
making any small adjustments which may be
necessary until the tread-belt is perfectly
centered.
