SPAZIO FORMA: Service & Maintenance manual - rev. 1.0
Page 10.4
10.4. YEARLY MAINTENANCE OPERATIONS
These operations can only be carried out by a qualified technician specifically trained by
Technogym and authorized to carry out machine installation and adjustments, as well as
special maintenance operations or repairs which require special knowledge of the
machine, its operation, safety systems and working procedures.
The yearly maintenance operations involve checking the operation, wear and tension of the
mechanical components so as to ensure perfect and safe operation of the machine.
For the yearly maintenance of the machine, proceed as follows:
10.4.1. CARRYING OUT THE ROUTINE MAINTENANCE PROCEDURE
1. Carry out the procedures described in paragraph 10.3. “Bimonthly maintenance operations”.
10.4.2. CHECKING THE WORKING CONDITIONS
1. Check that the machine is connected directly to the wall outlet, without any extension cords, and
that the outlet is correctly earthed.
2. Using a tester, check that the machine earth node is correctly connected to earth.
10.4.3. CHECKING THE WIRING AND CONNECTIONS
1. Open all the machine guards.
2. Check the condition of all the cables:
• External conditions;
• Possible rusting of the connectors;
• Electrical continuity of the individual wires;
• Isolation of the individual wires toward ground.
Repair and/or replace any non-conforming wires.
3. Check the condition of the fuse using a tester.
10.4.4. CHECKING THE WEAR AND LUBRICATION OF THE TREAD-BELT AND
RUNNING TRACK
Every 10000 km, or any time the tread belt or the rollers are disassembled, it is recommended to
perform the following checks:
1. Disassemble the rear and motor rollers, the running track and tread-belt.
2. Using a cloth, clean the entire surface of the running track and the inside of the tread-belt.
3. Check the state of wear of both the running track and tread-belt. Replace if they show significant
signs of wear.
4. Next, lubricate the full length of the running track and tread-belt with Silube spray oil.
5. After reassembling the machine, start the tread-belt at approximately 3 Km/h and walk on it,
taking care to tread on the entire width of the belt, so as to facilitate the uniform distribution of
the oil on its surface.
