SPAZIO FORMA: Service & Maintenance manual - rev. 1.0
Page 8.8
8.8. LEVELING
Figure 8.8-1
1. Remove the plastic cap a from one of the two
rear wheels.
Figure 8.8-2
2. Back off the screw b, using an 8-mm hex
wrench.
3. Rotate cam c using the special tool provided,
until all four wheels touch the ground.
4. Lock down screw b, holding the cam in
place.
Figure 8.8-3
5. If the two rear feet do not touch the ground,
to adjust them it is necessary to remove the
rear cover as follows:
• Back off the two screws d using a 6-mm
hex wrench;
• remove the cover;
Continued on the following page →
