6.1. THE DISPLAY DOES NOT ILLUMINATE
This problem occurs when the supply voltage fails to reach the display.
Are the f uses OK?
Is mains lead OK?
Does the wall outlet supply the
correct v oltage?
Replace the blown
fuses
Replace the mains lead
Connect machine to a
suitable
electrical outlet
THE DISPLAY
DOES NOT
ILLUMINATE
Is the mains v oltage present at
the power supply input?
NO
YES
NO
YES
NO
YES
NO
YES
1
A
B
Continued on the following page.
