SPAZIO FORMA: Service & Maintenance manual - rev. 1.0
Page 2.4
• Portable connectors
name type of connector connection
CN28 MOLEX mini-fit 7x2 m. portable to CPU board (actuator drive)
CN29 MOLEX mini-fit 7x2 f. portable to driver board (actuator drive)
CN30 MOLEX mini-fit 5x2 m. portable to CPU board (emergency signals / deck sensor)
CN31 MOLEX mini-fit 5x2 f. portable to power isolating board / deck position sensor
(emergency signals / deck sensor)
CN39 Terminal block to filter, power supply, inverter and selector
CN46 MOLEX mini-fit 3x2 f. portable to up-down motor
2.5.2. WIRING
SF-1A: Filter cable
Power inlet socket – Filter
Power inlet
socket
Signal Color Filter PE
Fast on Live Black Fast on -
Fast on Neutral Blue Fast on -
Fast on Yellow-green -
-
Earth
Yellow-green Fast on
Eyelet
This cable incorporates a 348 Ohm, 100 Mhz ferrite with coil on the live and neutral conductors.
SF-1B: High voltage power supply cable
Filter – High voltage distribution terminal block
Filter Signal Color Terminal block
CN39
Fast on Live Black L
Fast on Neutral Blue N
Fast on Earth Yellow-green PE
SF-2: Heart rate meter cable
CPU board – Heart rate receiver
CPU board
K15
Signal Color Receiver
1 +5 Vdc Red 1
2 Pulse per beat Blue 2
3 Gnd Black 3
