SPAZIO FORMA: Service & Maintenance manual - rev. 1.0
Page 9.6
9.5.1. MONITOR FUNCTION PARAMETERS
Parameter Description
d01 Motor output frequency
d02 Motor current draw
d04 Direction of movement
d05 Status monitor of intelligent terminal input signals
d06 Status monitor of intelligent terminal output signals
d07 “Converted” motor output frequency
d08 Monitor of last alarm condition
d09 List of the last error conditions
9.5.2. MODIFIED PARAMETER SETTINGS
The following table shows the parameters which must be configured with a different value from the
inverter defaults:
Parameter Description Value
A03 Base frequency setting 50
A04 Maximum frequency setting 80
A44 V/F Characteristic curve selection 02
A81 Selection of AVR function 01
A82 Selection of voltage of AVR function for the motor 240
b01 Selection of restart mode 02
b02 Allowable under voltage power failure time 25.0
b03 Time delay enforced before motor restarted 0.3
b12 Level of electronic thermal setting 8.00
b13 Electronic thermal characteristic 01
b22 Level of overload restriction setting 12.00
b83 Carrier frequency setting (KHz) 16.0
b90 Dynamic braking usage ratio 20
C03 Function of terminal 3 setting 12
C13 Condition of terminal 3 setting 01
F-02 Acceleration 10.0
F-03 Deceleration 10.0
H01 Auto-tuning setting 00
H02 Motor data selection 01
H03 Motor capacity setting 1.5
H04 Motor poles setting 4
H05 Motor constant K
p
setting 20
H06 Motor stabilization constant 100
H30 Motor constant R1 (Autotuning data) 1.124
H31 Motor constant R2 (Autotuning data) 1.500
H32 Motor constant L (Autotuning data) 8.99
H33 Motor constant Io (Autotuning data) 3.95
H34 Motor constant J (Autotuning data) 20
