SPAZIO FORMA: Service & Maintenance manual - rev. 1.0
Page 7.1
7. DISASSEMBLY OF COMPONENTS
7.1. DISASSEMBLING THE DISPLAY
Figure 7.1-1
1. Turn off the machine and unplug the mains
lead from the wall outlet.
2. Back off the 4 screws a using a phillips
screwdriver.
3. Unplug the cable connector.
4. Remove the DISPLAY.
To reassemble the DISPLAY, carry out the
above steps in reverse order.
