SPAZIO FORMA: Service & Maintenance manual - rev. 1.0
Page 7.13
Figure 7.10-4
4. Back off the 8 screws f which can be
accessed with a 10-mm socket wrench.
5. Reposition the tread belt on the ground.
Figure 7.10-5
6. Remove the FOOTRESTS GUIDE from the
rear side.
To reassemble the FOOTRESTS, carry out the
above steps in reverse order.
