Tektronix AFG3000 Series Reference Manual

Syntax and Commands
AFG3000 Series Arbitrary/Function Generators Reference Manual 3-85
[SOURce[1|2]]:VOLTage[:LEVel][:IMMediate][:AMPLitude]
This command sets or queries the output amplitude for the specified channel. If
your instrument is two channel model and the [SOURce[1|2]]:VOLTage:CONCur-
rent[:STATe] command is set to ON, then the output amplitude of the other
channel is the same value.
You can set the units of output amplitude by using either the bezel menu selection
or the [SOURce[1|2]]:VOLTage:UNIT command. The selection by bezel menu has
priority over the remote command.
Group
Source
Related Commands
[SOURce[1|2]]:VOLTage:CONCurrent[:STATe]
Syntax
[SOURce[1|2]]:VOLTage[:LEVel][:IMMediate][:AMPLitude]
{<amplitude>|MINimum|MAXimum}
[SOURce[1|2]]:VOLTage[:LEVel][:IMMediate][:AMPLitude]? {MINimum|
MAXimum}
Arguments
<amplitude>::=<NRf>[<units>]
where
<NRf> is the output amplitude.
<units>::=[VPP | VRMS | DBM]
Returns
<amplitude>
Examples
SOURce1:VOLTage:LEVel:IMMediate:AMPLitude 1V
sets the CH 1output amplitude to 1 V.
Units Amplitude resolution
VPP 0.1 mV
p-p
or four digits
VRMS 0.1 mV
rms
or four digits
DBM 0.1 dBm
