Appendix D: Default Setup
Table D-1 lists the settings that are restored when you push the front-panel Default
button.
Table D-1: Default settings
Menu or System Default setting
Output configuration
Function Sine
Frequency 1.000 000 000 00 MHz
Amplitude 1.000 V
p-p
Offset 0 mV
Symmetry (Ramp) 50.0%
Duty (Pulse) 50.0%
Output Units V
p-p
Output Impedance 50 Ω
Output Invert Off
Output Noise Add Off
External Add Off
Modulation
Modulation Waveform 10.00 kHz, Sine (except FSK)
Modulation Waveform 10.00 kHz, Square (FSK)
AM Depth 50.0%
FM Deviation 1.000 000 MHz
PM Deviation 90.0 °
FSK Hop Frequency 1.000 000 MHz
FSK Rate 50.00 Hz
PWM Deviation 5.0%
Sweep
Sweep Start Frequency 100.000 kHz
Sweep Stop Frequency 1.000 000 MHz
Sweep Time 10 ms
Sweep Hold Time 0 ms
Sweep Return Time 1 ms
Sweep Type Linear
Sweep Mode Repeat
Sweep Source Internal
Trigger Slope Positive
Trigger Interval 1.000 ms
