Syntax and Commands
3-10 AFG3000 Series Arbitrary/Function Generators Reference Manual
Mass Memory Commands. Mass Memory commands let you change mass memory
attributes. Table 3-8 lists and describes Mass Memory commands.
Output Commands. Output commands let you set output attributes. Table 3-9 lists
and describes Output commands.
Source Commands. Source commands let you set waveform output parameters.
Table 3-10 lists and describes Source commands.
Table 3-8: Mass Memory commands
Header Description
MMEMory:CATalog? Query the status of mass memory
MMEMory:CDIRectory Set/query current directory
MMEMory:DELete Delete file or directory in mass memory
MMEMory:LOAD:STATe Copy instrument setting in mass memory to setup memory
MMEMory:LOAD:TRACe Copy waveform data file in mass memory to edit memory
MMEMory:LOCK[:STATe] Set/query the lock of mass memory overwrite and deletion
MMEMory:MDIRectory Create directory in mass memory
MMEMory:STORe:STATe Save the setup memory status to mass memory
MMEMory:STORe:TRACe Save waveform data file in edit memory to mass memory
Table 3-9: Output commands
Header Description
OUTPut[1|2]:IMPedance Set/query impedance
OUTPut[1|2]:POLarity Set/query polarity
OUTPut[1|2][:STATe] Set/query output on or off
OUTPut:TRIGger:MODE Set/query the mode of Trigger Output
Table 3-10: Source commands
Header Description
[SOURce]:ROSCillator:SOURce Set/query clock reference input
[SOURce[1|2]]:AM:STATe Set/query amplitude modulation status
[SOURce[1|2]]:AM:INTernal:FREQuency Set/query internal modulation frequency
[SOURce[1|2]]:AM:INTernal:FUNCtion Set/query modulation waveform setting
[SOURce[1|2]]:AM:INTernal:FUNCtion:EFILe Set/query EFILe setting
[SOURce[1|2]]:AM:SOURce Set/query amplitude modulation source
[SOURce[1|2]]:AM[:DEPTh] Set/query amplitude modulation depth
[SOURce[1|2]]:BURSt:MODE Set/query burst mode
[SOURce[1|2]]:BURSt:NCYCles Set/query burst mode waveform output cycle
[SOURce[1|2]]:BURSt:TDELay Set/query burst mode trigger delay time
