Reference

2-2 AFG3000 Series Arbitrary/Function Generators Reference Manual

Menu Structure

This section describes the menus and operating details associated with each

front-panel menu button.

 Sine/Square Menu, page 2-3

 Ramp Menu, page 2-4

 Pulse Menu, page 2-4

 Arb Menu, page 2-5

 More... Menu, page 2-6

 Run Mode Menus

 Continuous (No bezel menu for Continuous mode)

 Modulation Parameter Menu, page 2-7

 Sweep Parameter Menu, page 2-9

 Burst Parameter Menu, page 2-11

 Output Menu, page 2-12

 Save/Recall Menu, page 2-13

 Edit Menu, page 2-14

 Utility Menu, page 2-23

NOTE. To access the Output menu, push the front-panel Top Menu button. The

arbitrary/function generator does not have the Output menu button on the front

panel. Refer to page 1-3 for the Top Menu button.
