1Ć8
Weight Weights that follow are nominal:
H 7.7 kg (17 lbs.), standĆalone instrument.
H 9.3 kg (20.5 lbs.), with front cover, accessories and accessories
pouch installed.
H 13.6 kg (30 lbs.), when packaged for domestic shipment.
Overall Dimensions Dimensions that follow are nominal:
Height:
H 191 mm (7.5 in.), when feet and accessories pouch are inĆ
stalled.
H 165 mm (6.5 in.), without the accessories pouch installed.
Width:
H 362 mm (14.25 in.), with handle.
Depth:
H 471 mm (18.55 in.), standĆalone instrument.
H 490 mm (19.28 in.), with optional front cover installed.
H 564 mm (22.20 in.), with fully handle extended.
Cooling Method ForcedĆair circulation with no air filter.
Finish Type Tektronix Blue textured paint finish on an aluminum cabinet.
Construction Material Chassis parts constructed of aluminum alloy; front panel conĆ
structed of plastic laminate; circuit boards constructed of glassĆlamiĆ
nate. Tektronix Blue textured paint finish on an aluminum cabinet.
Plastic parts are polycarbonate.
Weight of rackmounted instrument and
the rackmount conversion kit
Weights that follow are nominal:
H 4.5 kg (10 lbs.), for the rackmount conversion kit only; 7.9 kg
(17.5 lbs.), when kit is packaged for domestic shipping.
H 7.3 kg (16 lbs.) plus weight of rackmount Parts, for the rackĆ
mounted instrument (option 3R).
H 15.4 kg (34 lbs.), when the rackmounted instrument is packĆ
aged for domestic shipment (no manuals tray).
Overall Dimensions of the rackmount
instrument
Dimensions that follow are nominal:
H Height: 178 mm (7 in.).
H Width: 483 mm (19 in.).
H Depth: 472 mm (18.6 in.).
Including handles: 517 mm (20.35 in.).
