Tektronix TDS2024 User Manual

Appendix A: Specificati ons
TDS1000/2000-Series Digital Oscilloscope User Manual
157
Oscilloscope Specifications (Cont.)
Trigger
Trigger Sensitivity,
E
d
T
i
T
Coupling Sensitivity
g
g
y
,
Edge Trigger Type
DC
CH1, CH2,
CH3, CH4
1 div from DC to 10 MHz*,
1.5 div from 10 MHz* to Full
EXT 200 mV from DC to 100 MHz*,
350 mV from 100 MHz to
200 MHz*
EXT/5 1 V from DC to 100 MHz*,
1.5 V from 100 MHz to 200 MHz*
Trigger Sensitivity,
E
d
T
i
T
Coupling Sensitivity
g
g
y
,
Edge Trigger Type,
t
y
p
i
c
a
l
AC Same as DC at 50 Hz and above
t
y
p
i
c
a
l
NOISE
REJ
Reduces the DC-coupled trigger sensitivity by
2timesfor>10mv/divto5V/div
HF REJ Same as the DC-coupled limit from DC to 7 kHz,
attenuates signals above 80 kHz
LF REJ Same as the DC-coupled limits for frequencies
above 300 kHz, attenuates signals below 300 kHz
Trigger Level Range Source Range
g
g
g
CH1, CH2,
CH3, CH4
±8 divisions from center of screen
EXT ±1.6 V
EXT/5 ±8V
* Bandwidth reduced to 6 MHz with a 1X probe.

Tektronix TDS2024 Specifications

General

Channels	4
Bandwidth	200 MHz
Sample Rate	2 GS/s
Record Length	2.5k points
Vertical Resolution	8 bits
Vertical Sensitivity	2 mV/div to 5 V/div
Timebase Range	5 ns/div to 50 s/div
Display Resolution	320 x 240 pixels
Math Functions	Add, Subtract, Multiply, Divide, FFT
Input Coupling	AC, DC, GND
Trigger Modes	Auto, Normal, Single
Trigger Types	Edge, Video, Pulse
Connectivity	USB
Input Impedance	1 MΩ
Maximum Input Voltage	300 V
Interface	USB
Power Supply	100 to 240 V
Dimensions	326 mm x 158 mm x 124 mm
