TDS1000/2000-Series Digital Oscilloscope User Manual
127
TDS2CMA Communications Module
This chapter describes how to use the TDS2CMA Communications
Extension Module (optional) with a TDS1000- or TDS2000-series
oscilloscope.The TDS2CMA module adds Centronics, RS-232 and
GPIB communication ports to the oscilloscope. For ordering
information, refer to page 169.
This chapter describes how to do the following tasks:
H Install the exte nsion module
H Set up and test the RS-232 interface
H Set up and test the GPIB interface
H Send screen data to an external device (printer or computer)
Installing and Removing an Extension Module
This section describes how to safely remove and install an extension
module on your oscilloscope.

Tektronix TDS2024 Specifications

General

Channels	4
Bandwidth	200 MHz
Sample Rate	2 GS/s
Record Length	2.5k points
Vertical Resolution	8 bits
Vertical Sensitivity	2 mV/div to 5 V/div
Timebase Range	5 ns/div to 50 s/div
Display Resolution	320 x 240 pixels
Math Functions	Add, Subtract, Multiply, Divide, FFT
Input Coupling	AC, DC, GND
Trigger Modes	Auto, Normal, Single
Trigger Types	Edge, Video, Pulse
Connectivity	USB
Input Impedance	1 MΩ
Maximum Input Voltage	300 V
Interface	USB
Power Supply	100 to 240 V
Dimensions	326 mm x 158 mm x 124 mm
