Tektronix TDS2024 User Manual

TDS1000/2000-Series Digital Oscilloscope User Manual
179
Appendix E: GPIB and RS -232 In terfaces
The next table provides an in-depth comparison of the GPIB and
RS-232 interfaces. You should select the interface that best me ets
your requirements.
GPIB and RS-232 interface comparison
Operating attribute
GPIB RS-232
Cable IEEE-488 Std. 9-wire
Data flow control Hardware, 3-wire hand-
shake
Flagging:
soft (XON/XOFF),
hard (RTS/CTS)
Data format 8-bit parallel 8-bit serial
Interface control Operator low-level con-
trol message
None
Interface messages Most IEEE-488 Std. Device clear using a
break signal
Interrupts reported Service requests, status
and event code
None, must be polled for
status

Tektronix TDS2024 Specifications

General

Channels	4
Bandwidth	200 MHz
Sample Rate	2 GS/s
Record Length	2.5k points
Vertical Resolution	8 bits
Vertical Sensitivity	2 mV/div to 5 V/div
Timebase Range	5 ns/div to 50 s/div
Display Resolution	320 x 240 pixels
Math Functions	Add, Subtract, Multiply, Divide, FFT
Input Coupling	AC, DC, GND
Trigger Modes	Auto, Normal, Single
Trigger Types	Edge, Video, Pulse
Connectivity	USB
Input Impedance	1 MΩ
Maximum Input Voltage	300 V
Interface	USB
Power Supply	100 to 240 V
Dimensions	326 mm x 158 mm x 124 mm
