Appendix C: General Care an d Cleaning
General Care
Do not store or leave the instrument where the LCD display will be
exposed to direct sunlight for long periods of time.
CAUTION. To avoid damage to the instrument or probes, do not
expose them to sprays, liquids, or solvents.
Cleaning
Inspect the instrument and probes as often as operating conditions
require. To clean the exterior surface, perform the following steps:
1. Remove loose dust on the outside of the instrument and probes
with a lint-free cloth. Use ca re t o avoid scratching the clear
plastic display filter.
2. Use a soft cloth dampened with water to clean the instrument.
Use an aqueous solution of 75% isopropyl alcohol for more
efficient cleaning.
CAUTION. To avoid damage to the surface of the instrument or
probes, do not use any abrasive or chemical cleaning agents.

Tektronix TDS2024 Specifications

General

Channels	4
Bandwidth	200 MHz
Sample Rate	2 GS/s
Record Length	2.5k points
Vertical Resolution	8 bits
Vertical Sensitivity	2 mV/div to 5 V/div
Timebase Range	5 ns/div to 50 s/div
Display Resolution	320 x 240 pixels
Math Functions	Add, Subtract, Multiply, Divide, FFT
Input Coupling	AC, DC, GND
Trigger Modes	Auto, Normal, Single
Trigger Types	Edge, Video, Pulse
Connectivity	USB
Input Impedance	1 MΩ
Maximum Input Voltage	300 V
Interface	USB
Power Supply	100 to 240 V
Dimensions	326 mm x 158 mm x 124 mm
