TDS1000/2000-Series Digital Oscilloscope User Manual
175
Appendix D: Default Setup
This appendix describes the options, buttons and controls that change
settings when you push the DEFAULT SETUP button. For a list of
settings that do not change, refer to page 178.
NOTE. When you push the DEFAULT SETUP button, the oscilloscope
displays the CH1 waveform and removes all other waveforms.
Default settings
Menu or system
Option, button or knob Default setting
ACQUIRE (three mode options) Sample
Averages 16
RUN/STOP RUN
CURSOR Type Off
Source CH1
Horizontal (voltage) +/-- 3.2 divs
Vertical (time) +/-- 4 divs
DISPLAY Type Vectors
Persist Off
Format YT
HORIZONTAL Window Main
Trig Knob Level
POSITION 0.00 s
S
E
C
/
D
I
V
5
0
0

s
S
E
C
/
D
I
V
5
0
0
s
Window Zone
50 s

Tektronix TDS2024 Specifications

General

Channels	4
Bandwidth	200 MHz
Sample Rate	2 GS/s
Record Length	2.5k points
Vertical Resolution	8 bits
Vertical Sensitivity	2 mV/div to 5 V/div
Timebase Range	5 ns/div to 50 s/div
Display Resolution	320 x 240 pixels
Math Functions	Add, Subtract, Multiply, Divide, FFT
Input Coupling	AC, DC, GND
Trigger Modes	Auto, Normal, Single
Trigger Types	Edge, Video, Pulse
Connectivity	USB
Input Impedance	1 MΩ
Maximum Input Voltage	300 V
Interface	USB
Power Supply	100 to 240 V
Dimensions	326 mm x 158 mm x 124 mm
