Tektronix TDS2024 User Manual

Getting Started
2
TDS1000/2000-Series Digital Oscilloscope User Manual
General Features
The next table and bulleted list describe the general features.
Model Channels Bandwidth Sample rate Display
TDS1002 2 60 MHz 1.0 GS/s Monochrome
TDS1012 2 100 MHz 1.0 GS/s Monochrome
TDS2002 2 60 MHz 1.0 GS/s Color
TDS2012 2 100 MHz 1.0 GS/s Color
TDS2014 4 100 MHz 1.0 GS/s Color
TDS2022 2 200 MHz 2.0 GS/s Color
TDS2024 4 200 MHz 2.0 GS/s Color
H Context-sensitive Help system
H Color or monochrome LCD display
H Selectable 20 MHz bandwidth limit
H 2500 point record length for each channel
H Autoset Menu
H Probe Check Wizard
H Cursors with readouts
H Trigger frequency readout
H Eleven automatic measurements
H Waveform averaging and peak detection

Tektronix TDS2024 Specifications

General

Channels	4
Bandwidth	200 MHz
Sample Rate	2 GS/s
Record Length	2.5k points
Vertical Resolution	8 bits
Vertical Sensitivity	2 mV/div to 5 V/div
Timebase Range	5 ns/div to 50 s/div
Display Resolution	320 x 240 pixels
Math Functions	Add, Subtract, Multiply, Divide, FFT
Input Coupling	AC, DC, GND
Trigger Modes	Auto, Normal, Single
Trigger Types	Edge, Video, Pulse
Connectivity	USB
Input Impedance	1 MΩ
Maximum Input Voltage	300 V
Interface	USB
Power Supply	100 to 240 V
Dimensions	326 mm x 158 mm x 124 mm
