Appendix A: Specificati ons
160
TDS1000/2000-Series Digital Oscilloscope User Manual
Oscilloscope Specifications (Cont.)
Trigger Frequency Counter
Readout Resolution 6 digits
Accuracy (typical) ±51 ppm including all frequency reference errors and ±1 count
errors
Frequency Range AC coupled, 10 Hz minimum to rated bandwidth
Signal Source Pulse Width or Edge Trigger modes: all available trigger sources
The Frequency Counter measures trigger source at all times,
including when the oscilloscope acquisition is halted due to
changes in the run status, or acquisition of a single shot event
has completed.
Pulse Width Trigger mode: The oscilloscope counts pulses of
significant magnitude inside the 250 ms measurement window
that qualify as triggerable events, such as narrow pulses in a
PWM pulse train if set to < mode and the width is set to a
relatively small time.
Edge Trigger mode: The oscilloscope counts all edges of
sufficient magnitude and correct polarity.
Video Trigger mode: The Frequency Counter does not operate.

Tektronix TDS2024 Specifications

General

Channels	4
Bandwidth	200 MHz
Sample Rate	2 GS/s
Record Length	2.5k points
Vertical Resolution	8 bits
Vertical Sensitivity	2 mV/div to 5 V/div
Timebase Range	5 ns/div to 50 s/div
Display Resolution	320 x 240 pixels
Math Functions	Add, Subtract, Multiply, Divide, FFT
Input Coupling	AC, DC, GND
Trigger Modes	Auto, Normal, Single
Trigger Types	Edge, Video, Pulse
Connectivity	USB
Input Impedance	1 MΩ
Maximum Input Voltage	300 V
Interface	USB
Power Supply	100 to 240 V
Dimensions	326 mm x 158 mm x 124 mm
