Specifications (cont.)
Inputs
Differential delay,
typical
100 ps between any two channels with the same scale and
coupling settings
Vertical
Number of channels TDS30x2B TDS30x4B
2 plus external trigger input 4 plus external trigger input
Digitizers 9-bit resolution, separate digitizers for each channel, sampled
simultaneously
SCALE Range
(
B
N
C
)
1MΩ 50 Ω
g
(at BNC)
1mV/divto10V/div 1mV/div to 1 V/div
Fine SCALE Adjustable with ≥ 1% resolution
Polarity Normal and Invert
Position range ±5 divisions
n Analog bandwidth,
50 Ω
Bandwidth limit set to Full, operating ambient ≤30 °C,
derate 1% / °C above 30 °C
(also typical at 1 MΩ
with standard probe)
Scale range
5mV/divto
1V/div
2mV/divto
4.98 mV/div
1mV/divto
1.99 mV/div
TDS301xB 100 MHz 100 MHz 90 MHz
TDS302xB 200 MHz 100 MHz 90 MHz
TDS303xB 300 MHz 250 MHz 150 MHz
TDS304xB 400 MHz 250 MHz 150 MHz
TDS305xB 500 MHz 300 MHz 175 MHz
TDS306xB 600 MHz
1
300 MHz 175 MHz
Calculated rise time,
i
l
TDS301xB, TDS302xB 3.5 ns
,
typical
TDS303xB, TDS304xB 1.2 ns
TDS305xB, TDS306xB 0.7 ns
1
500 MHz at 5 mV/div; 600 MHz at 10 mv/div and greater.
