Appendix B: Factory Setup
TDS3000B Serie s User Manual
B-3
Control Changed by factory setup to
Horizontal delay time 0ns
Horizontal trigger position 10%
Horizontal time/div
400 s/div
Horizontal zoom Off
Horizontal zoom position 50%
Horizontal zoom time/div
400 s/div
Math type Dual waveform
Measure gating Off (Full Record)
Measure high-low setup Auto
Measure high reference 90% and 0 V
Measure indicators Off
Measure low reference 10% and 0 V
Measure mid reference 50% and 0 V
Measure mid2 reference 50% and 0 V
Measure statistics Off
Overwrite lock No change
Phase measure to waveform Ch 1
Reference waveforms No change
Saved setups No change
Trigger holdoff 250.8 ns
Trigger mode Auto
Trigger type Edge
