Reference
Screen button Function
← and →
Moves the cursor to a different character in the field.
Back Space Deletes the character before the cursor location.
Delete Deletes the c
haracter at the cursor location.
Clear Erases the c
urrent field value.
↑ and ↓
Selects the
field that you want to edit.
OK Accept Applies al
l field values.
Menu Off Exits the
menu without applying field values.
Deleting Files. To delete a file, select the fi le with the general purpose knob, push
the Delete screen button, and then push the OK Delete screen button when you
see the confirmation screen.
If you do not want to see a confirmation screen each time you delete a file, push
the Confirm Delete screen button to set it to Off.
Renaming Files. To rename a file, select the file with the general purpose knob,
push the Rename screen button, and then edit the file name. (See page 87.)
Once a directory is created, you cannot rename it. However, you can delete the
directory and create a new one with a new name.
Copying Files and Directories. To copy a file or directory, select the file or
directory with the general purpose knob and push the Copy screen button. Now
use the general purpose knob and Select button to select a destination directory.
Push the copy confirmation screen button to complete the operation.
Printing Files. Yo u ca n pri nt files through any installed printer port to your printer.
To print a file, select the fi le with the general purpose knob. Push the Print screen
button and then select the port to which your printer is connected. Make sure that
the oscilloscope is set to send the correct file format to your printer.
88 TDS3000C Series Oscilloscope User Manual
