Appendix A: Specifications
I/O Ports
Ethernet port
10BaseT RJ-45 female connector (all m odels)
GPIB interface Available in optional accessory TDS3G V
RS-232 interface
DB-9 male con
nector, available in optional accessory
TDS3GV
USB flash drive port USB fl ash drive connector (all models)
VGA signal output DB-15 female connector, 31.6 kHz sync r ate, EIA RS-343A
compliant, available in optional accessory TDS3GV
Probe compensator output,
typical
5.0Vinto≥1MΩ load,
Frequenc
y=1kHz
Miscellaneous
Nonvolatile memory
Typical retention time ≥ 5 years for front-panel settings,
unlimite
d for saved waveforms and setups
Internal clock
Provide
s date/time stamp for stored data and the current
time and date to the front panel, if enabled.
Power so
urce
AC line
power
Operat
es the oscilloscope and charges the optional internal
battery
Source voltage 100 V
RMS
to 240 V
RMS
± 10%, continuous range
Source frequency
47 Hz t
o 440 Hz
Power
consumption
75 W ma
ximum
Battery power
Opti
onal accessory TDS3BATC, rechargeable Li-Ion battery
pack
Operating time, typical
3ho
urs, depending on operating conditions
Bat
tery charge tim e, typical
32 h
ours in the oscilloscope, 6 hours in the optional external
charger TDS3CHG
Line fuse
In
ternal, not replaceable
En
vironmental
Temperature
1
,
2
,
3
Op
erating range:
0 °C to +50 °C (+32 °F to +122 °F)
Nonoperating range (storage):
-
40°Cto+71°C(-40°Fto+160°F)
Humidity
1
5
% to 95% RH below 30 °C (+86 °F), derate upper limit to 45% RH at
50 °C (+122 °F)
Pollution
Degree
Pollution Degree 2: indoor use only
