Appendix A: Specifications
Environmental
Altitude
4
,
5
Operating lim
it: 3,000 m (3,280 yd.)
Nonoperating limit: 15,000 m (16,404 yd.)
Random
vibration
Operating: 0.31 g
RMS
from 5 Hz to 500 Hz, 10 m inutes on each axis
Nonoperating: 2.46 g
RMS
from 5 Hz to 500 Hz, 10 minutes on each axis
1
When a battery pack is installed, refer to the TDS3BATC Rechargable Battery Pack Instructions (Tektronix
part number 071-0900-04) for information on the charge, discharge and storage requirements for temperature
and humidity.
2
Keep two inches of clearance at all ventilation openings.
3
The maximum operating ambient air temperature for this product is 50 °C (measured at the air intake vent on the
rear of the pr
oduct). Do not exceed this temperature when operating the instrument.
4
This product's maximum operating altitude is 3000 m. If used in aircraft, this product should be kept in a
environment pressurized to no greater than 3000 m altitude.
5
Probes used with this product may have different maximum altitude ratings, possibly including an altitude rating
of only 2000 m. Review the specifications f or the particular probe you plan to use with the product and be
sure that it is within its ratings during use.
Mechanical
Size Height: 176 mm (6.9 in), 229 mm (9.0 in) including handle
Width: 375 mm (14.75 in)
Depth: 149 mm (5.9 in)
Weight
Oscilloscope only: 3.2 kg (7.0 lbs)
With accessories and carry case: 4.1 kg (9.0 lbs)
When packaged for domestic shipment: 5.5 kg (12.0 lbs)
Optional TDS3BATC battery pack: 0.85 kg (1.9 lbs)
130 TDS3000C Series Oscilloscope User Manual
