Appendix B: Factory Setup
Control Changed by factory setup to
External trigger probe setup (four-channel
models only)
Voltage, 1X
Horizontal delay
On
Horizontal delay time 0 ns
Horizontal
trigger position
10%
Horizontal time/div 400 ms/div
Horizonta
l zoom
Off
Horizont
al zoom position
50%
Horizontal zoom time/div 400 ms/div
Math typ
e
Dual waveform
Measure
gating
Off (Full Record)
Measur
e high-low setup
Auto
Measu
re high reference
90% an
d0V
Measure indicators
Off
Meas
ure low reference
10% a
nd0V
Meas
ure mid reference
50% a
nd0V
Mea
sure mid2 reference
50%
and0V
Measure statistics
Of
f
Ov
erwrite lock
No change
P
hase m easure to waveform
C
h1
R
eference waveforms
No change
Saved setups
No change
Trigger holdoff
250.8 ns
Trigger mode Auto
Trigger type Edge
Utility language No change
Utility date/time display On
Utility I/O
No change
Utility hard copy No change
Vertical bandwidth Full
Vertical coupling
DC 1 M Ω
Vertical invert
Off
Vertical offset
0V
Vertical position 0 div
Vertical probe setup
Voltage, 1 X (unless a non-1 X probe is
attached)
Vertical volts/div 100 mV/div
Video trigger standard
525/NTSC
Video trigger on All lines
132 TDS3000C Series Oscilloscope User Manual
