Appendix F: Ethernet Setup

Ethernet Sett

ings Form

TDS3000C Ethernet Setup Form for: ______________________________________

TDS3000C Ethernet Hardware address _____ : _____ :_____ :_____ :_____ :

(Copy this address from the U tility > System: I/O > Ethernet Network Settings > Change Instrument Setup screen before

sending this form to the network administrator.)

Type of IP address requested: Dynamic (DHCP/BOOTP) - □ Static -□

(Refer to the beginning of this appendix for information on dynamic and static IP addresses. (See page 149, Ethernet Setup.))

IP address settings (from network admin.):

Instrument Name: ____________________________________________

Instrument (IP) Address: ______.______.______.______

Domain Name: ___________________

DNS IP Address: ______.______.______.______

Gateway IP Address: ______.______.______.______

Subnet mask: ______.______.______.______

HTTP Port: ___________________

(Enter these values on the Utility > I/O > E thern et Network Setting s > Change Instrument Settings screen.) (See

page 149, Ethernet Setup.)

Network Administrator: Please provide network information about the following printer:

Printer Location: _____________________________________________

Printer Make: ___________________

Model: ___________________

(User: ﬁll in above printer information before sending form)

Printer Network Name: ___________________

Printer Server Name: ___________________

Print Server IP Address: ______.______.______.______

(Enter the above information on the Utility > I/O > Ethern e t Printer Settings > Add Printer screen.)

TDS3000C Series Oscilloscope User Manual 157
