Appendix F: Ethernet Setup
3. Push Utility > S
ystem to select Hard Copy.
4. Push the Format bottom button and select the side button that is correct for
your network p
rinter.
5. Push the Port bottom button and select the Ethernet side button.
6. Set Inksaver to ON to print the oscilloscope s creen as a black on white
background image.
7. Push the Menu Off button to exit from the System Hard Copy menus.
Testing Network Printers
To test that your oscilloscope is set to print to a network printer, push the Hard
copy button. The printer should print the current screen to the selected network
printer. If the printer does not print the screen, refer to the troubleshooting
suggestions. (See page 152, Troubleshooting Your Ethernet Connection.)
Ethernet Error Messages
The following error messages can occur when you are having network problems.
Read th
e text that follows to help rectify the problem.
Print Server Not Responding. This notifier displays when the oscilloscope
attempts to send data to the selected network printer but the network refuses the
connection to the network printer. This usually means that the network printer
server is offline or the print server IP address is incorrect.
If DNS is available then you can verify the network print server data by entering
the printer name and either (but not both) the print server name or the IP address.
The
DNS protocol will fill in the missing data if the user-supplied data is correct.
If DNS is not available, then contact your network administrator for help.
Printer Not Responding. This notifier displays when the oscilloscope attempts to
send data to the selected network printer but the print server is unable to forward
the data to the network printer. This usually means that the network printer is
offline or the printer name is incorrect. Contact your network administrator to
obtain the correct printer queue name.
DNS Server Not Responding. This notifier displays when either the Domain
information (Domain name or IP address) is not correct, or the print server name
or printer server IP address is not validated (via the Domain Name Server).
156 TDS3000C Series Oscilloscope User Manual
