Appendix F: Ethernet Setup
Testing Network Printing
To test sending
screen hard copy images to an Ethernet network printer, follow
these steps:
1. On the oscillo
scope, push Utility > System : I/O > Ethernet Printer
Settings.
2. Select a net
work printer from the list.
3. Push the System bottom button to select Hardcopy.
4. Push the appropriate bottom and side menu buttons to select the correct
settings for y our network printer.
5. Push Menu Off to clear the screen.
6. Push the Hard Copy button. The oscilloscope sends a hard copy screen
image to the selected network printer. If the printer does not print the
oscilloscope screen, refer to the troubleshooting suggestions. (See page 152,
Trouble
shooting Your Ethernet Connection.)
Testing e*Scope
To use the e*Scope feature to test your oscilloscope's Ethernet connection, follow
these steps:
1. On a PC or work station, open your preferred b rowser program.
2. In the Location or A ddress field (where you normally enter a URL), type in
the IP address of the TDS3000C Series oscilloscope to which you want to
connect. For example, http://188.121.212.107. Do not precede the IP address
wit
h any char acters (such as www).
3. Push the Return key. The browser program loads the oscilloscope's
e*S
cope home page. If the e*Scope home page does not display, refer to the
troubleshooting suggestions. (See page 152, Troubleshooting Your Ethernet
Connection.)
Troubleshooting Your Ethernet Connection
If you are not able to remotely access the oscilloscope using e*Scope or
programming commands, work with your system administrator to verify that:
Your oscilloscope is physically connected to the network.
Your oscilloscope network settings are correct.
Your system administrator can "ping" the oscilloscope to verify that the
oscilloscope is electronically connected to the network.
152 TDS3000C Series Oscilloscope User Manual
