Appendix F: Ethernet Setup
Entering the N
etwork Printer Settings
To enter the Ethernet printer settings information from section 2 of the form into
your oscilloscope, follow these steps:
1. Push the Utility front panel button.
2. Push the System bottom button to select I/O.
3. Push the Ethernet Printer Settings bottom button. The oscilloscope displays
the Printer Configuration screen, which lists all network printers loaded into
the oscilloscope.
4. Push the Add Printer side button. The oscilloscope displays the Add Printer
screen.
5. Use the Add Printer screen menu items and controls to enter the network
printer information from section 2 of the form. (See page 155, The Add
Printer Screen.)
NOTE. If you have set the domain name and DNS IP address in the Ethernet
Network Settings menu, then all you need to enter is the network printer's server
name or the printer's se rver IP address in the Add Printer screen. The DNS server
will look up the missing information.
6. When you are done entering the Ethernet printer settings, push the OK Accept
side button to store the settings in your oscilloscope. The oscilloscope returns
you to the Printer Configuration screen, which lists the printer information
you just entered. You can enter and store multiple network printer parameters.
Testing Your Ethernet Connection
You must already have entered the oscilloscope Ethernet network and printer
settings before you test the Ethernet connection, network printing, and the
e*Scope feature.
Testing the Oscilloscope
Connection
To test your oscilloscope's Ethernet connection, follow these steps:
1. Push the Utility front panel button.
2. Push the System bottom button to select I/O.
3. Push the Ethernet Network Settings bottom button to display the Network
Configuration side menu.
4. Push the Tes t Co nne ction side button. If the connection is good, the side
menu displays OK. If you do not see OK, refer to the troubleshooting
suggestions. (See page 152, Troubleshooting Your Ethernet Connection .)
TDS3000C Series Oscilloscope User Manual 151
