Appendix F: Ethernet Setup
The Add Printe
rScreen
The next figure shows the Add Printer screen. The text tha t follows describes the
screen menu items and c ontrols for entering printer configuration settings.
Add Printer Control Description
General purpose knob Selects (highlights) an alphanumeric character in the list.
Enter Character
Adds the selected alphanumeric character to the current
printer setting fi eld. You can also use the front panel
Select button. The list of available characters changes
depending on which field is selected.
← and →
Moves the cursor left or right in the current field.
Back Space Erases the character to the left of the cursor.
Delete Erases the character at the cursor position.
Clear Clears (erases) the current field.
↑ and ↓
Selects a fi eld to edit.
OK Accept Closes the Add Printer s creen and applies the printer
settings. You can use the new printer i mmediately.
Menu Off Closes the Add Printer screen and returns you to the
previous screen without applying changes.
Other Network Printer
Settings
To verify that your oscilloscope is set to print to a network printer, follow these
steps:
1. Select a network printer in the Ethernet printer list. You select a printer by
using the general purpose knob to highlight a printer name in the list.
2. Push the Menu Off button to exit from the System I/O menus.
TDS3000C Series Oscilloscope User Manual 155
