Appendix A: Specifications
Environmental
Temperature
1
,
2
,
3
Operating range:
0 °C to +50 °C (+32 °F to +122 °F)
Nonoperating range (storage):
-40 ° C to +71 °C (-40 °F to +1 60 °F)
Humidity
1
5% to 95% RH below 30 °C (+86 °F), derate upper limit to
45% RH at 5 0 °C (+122 °F)
Pollution
Degree
Pollution Degree 2: indo
or use o nly
Altitude
4
,
5
Operating limit: 3,000 m (3,280 yd.)
Nonoperating limit: 15,000 m (16,404 yd.)
Random
vibration
Operating: 0.31 g
RMS
from 5 Hz to 500 Hz, 1 0 m inu tes on
each axis
Nonoperating: 2.46 g
RMS
from 5 Hz to 500 Hz, 10 minutes
on each axis
1
When a battery pack is installed, refer to the TDS3BATC Rechargable Battery Pack
Instructions (Tektronix part number 071-0900-04) for information on the charge, discharge
and storage re
quirements for temperature and humidity.
2
Keep two inches of clearance at all ventilation openings.
3
The maximum operating ambient air temperature for this product is 50 °C (measured at
the air intake vent on the rear of the product). Do not exceed this temperature when
operating the instrument.
4
This product's maximum operating altitude is 3000 m . If used in aircraft, this product
should be ke
pt in a environment pressurized to no greater than 3000 m altitude.
5
Probes used w ith this product may have different maximum altitude ratings, possibly
including an altitude rating of only 2000 m. Review the specifications for the particular
probe you plan to use with the product and be sure that it is within its ratings during use.
Mechanical
Size Height: 176 mm (6.9 in), 229 mm (9.0 in ) including handle
Width: 375 mm (14.75 in)
Depth: 149 mm (5.9 in)
Weight
Oscil
loscope only: 3.2 kg (7.0 lbs)
With
accessories and carry case: 4.1 kg (9.0 lbs)
Whe
n packaged for domestic shipm ent: 5.5 kg (12.0 lbs)
Opt
ional TDS3BATC battery pack: 0.8 5 kg (1.9 lbs)
160 TDS3000C Series Oscilloscope User Manual
