Voltage derating for THDP0100 probe standard accessories
The THDP0200 and TMDP0200 standard accessories can be used with the THDP0100 probe at the reduced voltage levels listed in this
table.
Table 1: Combined probe and accessory common-mode voltage and input voltage-to-earth ratings
Accessory THDP0100 THDP0200 TMDP0200
Extender leads (196-3523-xx) 2300 V CAT I 1000 V CAT III 1000 V CAT II 600 V CAT III 550 V CAT I 300 V CAT III
Test probe (TATP) (part of
020-3070-xx kit)
1000 V CAT I 1000 V CAT II 1000 V CAT II 600 V CAT II 550 V CAT I 300 V CAT II
Small hook tip (TASH) (part of
020-3070-xx kit)
2300 V CAT I 1000 V CAT II 1000 V CAT II 600 V CAT II 550 V CAT I 300 V CAT II
Large hook tip (TALH) (part of
020-3070-xx kit)
2300 V CAT I 1000 V CAT II 1000 V CAT II 600 V CAT II 550 V CAT I 300 V CAT II
Voltage derating for THDP0200 and TMDP0200 probe standard accessories
The operating altitude of the probe is derated to 2000 m (6560 ft) when used with these accessories.
The voltage rating and CA
T rating are derated to the voltage in this table when used with these accessories.
Table 2: Combined probe and accessory common-mode voltage and input voltage-to-earth ratings
Accessory THDP0100 THDP0200 TMDP0200
Extender leads (196-3523-xx) 2300 V CAT I 1000 V CAT III 1000 V CAT II 600 V CAT III 550 V CAT I 300 V CAT III
Handheld probes (TP175) 1000 V CAT I 1000 V CAT III 1000 V CAT II 600 V CAT III 550 V CAT I 300 V CAT III
Pogo pin tip adapters and tips
(020-3107-xx)
150 V CAT II 150 V CAT II 150 V CAT II
Extended test probe adapters
(012-1724-xx)
300 V CAT I300 V CAT II 300 V CAT II 300 V CAT I300 V CAT II
Hook clips (AC280-FL) 1000 V CAT I 1000 V CAT III 1000 V CAT II 600 V CAT III 550 V CAT I 300 V CAT III
Pincer clips (AC283-FL) 1000 V CAT I 1000 V CAT III 1000 V CAT II 600 V CAT III 550 V CAT I 300 V CAT III
Alligator clips (AC285-FL) 1000 V CAT I 1000 V CAT III 1000 V CAT II 600 V CAT III 550 V CAT I 300 V CAT II
Crocodile clips (344-0670-xx) 300 V CAT I 300 V CAT I 300 V CAT I
The THDP0100 probe can be used with these accessories at the reduced voltage levels listed in this table.
When using the TP175 test probes in CA
T III circuits, the tip must be in the retracted position to prevent risk of arc flash. The exposed
metal tip is about 3.7 mm (0.15 in) in the retracted position.
