Incoming Inspection
6. Select Network
Settings > IP Address.
7. Set the IP Address to be compatible with the computer:
a. Use the left/right arrow keys to move the highlight to each box in the
address.
b. Use the up/down arrow k eys to change the number in each box as required.
c. To accept your changes, move the highlight to the Accept box and press
SEL.
d. Enable the ethernet connection from the Configurationmenubyselecting
Network Settings > Web Enable > On.
8. Open a Web browser on the computer.
9. From the computer, enter the IP address of the waveform monitor into the
Web b rowser address line (for example, http://192.182.256.23).
10. You should see a Web page titled “Tektronix WFM6120/WFM7120 Remote
Interface” or something similar. This means that the Ethernet function is
working.
11. Record Pass or Fail for Ethernet Functionality in the test record.
NOTE. While in Simultaneous Input mode, certain displays can be displayed
either on the left or on the right, but not both at the same time.
NOTE. This test exercises the ability to simultaneously display signals from
two inputs. The two input signals may be of any type and format supported by
installed options (HD, CPS, DL). This procedure assumes Option HD is installed.
If Option HD is not installed, then any supported signal type may be used in
its place with similar results.
Simultaneous Input
Operation Test (Option
SIM)
1. Set up a signal generator with an HDVG1 module and a DVG1 module.
Connect an output from the HDVG1 module to the SDI A input of the
instrument under test.
2. Connect an output from the DVG1 module to the SDI B input of the
instrument under test.
3. Set the HDVG1 m odule format to 1080 59.94i 100% color bars.
4. Set the DVG1 module format to 525-270 SMPTE color bars.
5. Restore the Factory Preset. (See page 60, Restore the Factory Presets.)
6. Press the CONFIG button.
7. Select Input Mode > Simultaneous.
76 Waveform Monitors Specifications and Performance Verification
