2 Functions and Options
2.1 EN 54-2 – Options with Requirements
The TSA-200 product family conforms fully to European standards BS EN 54-2:1998
(including Amendment A1:2006) and EN 54-4:1998 (including Amendments A1:2002
and A2:2006) and the following optional features:
• Output to fire alarm devices – EN 54-2 Section 7.8 option with requirements
• Output to fire alarm routing Equipment – EN 54-2 Section 7.9 option with
requirements
• Output to fire alarm protection Equipment – EN 54-2 Section 7.10 option with
requirements(TSA-200XT and TSA-240XT only)
• Dependencies on more than one alarm signal - EN 54-2, section. 7.12 (type A or
type B), option with requirements.
• Total loss of power supply – EN 54-2 Section 8.4 option with requirements
• Output to fault warning routing Equipment – EN 54-2 Section 8.9 option with
requirements
• Test condition – EN 54-2 Section 10 option with requirements
2.2 UL 864
The TSA-200 / TSA-200XT / TSA-240 / TSA-240XT, human interface also conforms to
UL 864 edition 9.
2.3 TSA-200XT / TSA-240XT Extinguishing-Specific
Functions
In addition to the EN 54-2 requirements and options with requirements detailed above,
the TSA-200XT and TSA-240XT also provides the following additional functions
• Extinguishing Delay, 0 or 30 Sec, User Programmable. (Default -No delay)
• Extinguishing Pulse Duration, 20 seconds.
• Extinguishing Inhibit (Abort/Hold) input.
• Manual Release (extinguishing Trigger) input
• Manual Release delay (Default-No delay)
2.4 Additional Functions
In addition to the EN 54-2 requirements and options with requirements detailed above,
the TSA-200 product family also provides the following additional functions
• Auxiliary 24V outputs.
• Detectors maintenance alert (For Telefire's detectors ONLY)
2.5 Support Functions
• Lights (LEDs) Test
