4.2 Terms and Definitions
TERM MEANING
Event A change which is detectable by the ECD and (usually) causes a response.
Assert Fulfill requirements and cause a response.
4.3 Functional Drawing
Figure 1 TSA-200 / TSA-200XT System Symbolic Functional Diagram
The TSA-200/ TSA-240 is Fire Alarm Control Panel (FACP), also termed a Control and
Indication Equipment (CIE). It relates to the left side of Figure 1.
The blocks enclosed in the dashed line (to the right side of the diagram) are the
additions located in the EM1 extinguishing Expansion Module.
With the Extinguishing module assembled and operational, the unit becomes the TSA-
200XT / TSA-240XT, a Fire Alarm and Extinguishing Control Panel.
