TSA-200 / TSA-200XT / TSA-240 / TSA-240XT
© 2010 – 2014 Telefire Fire & Gas Detectors Ltd Revision 1.06 July 2014
Page 59 of 79
16.4 Entering the Programming Mode
Press Menu to enter the main menu. The Password LED will flash – enter the
password (default – 2222 for level 3 access).
16.5 Exiting the Programming Mode
To exit the programming mode you can press Test/Save to save your programming and
exit the menu, or press Reset, to exit the menu, and discarding the programming
changes.
16.6 Keyboard Keys Functions during Programming
The keyboard has different functions in programming mode.
Key Function in Programming Mode
Menu
Entering the Menu. Moves the "cursor" between programming menus
(test; enable/disable; delay; activation conditions; removal of
extinguishing module)
Select
Moves the "cursor" between fields (zone 1; zone 2; sounders;
alarm/released dialer; FWRE; extinguishing)
Enable/Disable
Performs the following functions, depending on specific
circumstances:
• Starts or stops test mode for a zone
• Enables or disables a zone, horn output; alarm dialer, FWRE; or
extinguishing output
• Sets or removes delay for a zone; horn output; alarm dialer;
FWRE; or extinguishing output
• Sets the extinguishing activation conditions (only zone 1; only
zone 2; or both at the same time)
• Disables the extinguishing module
Test/Save
In programming, saves changes and exits programming.
When not in programming, switches all LEDs ON.
Reset
Exits the programming mode without saving programming changes.
16.7 Display during Programming
During programming a flashing LED indicates the programming field.
16.8 Programming Sequence
16.8.1 Programming Process
• Enter programming mode by pressing Menu
• Enter the password (default: 2222)
• Press Menu to navigate between menus
• Press Select to navigate between fields
• Select the required option by pressing Enable / Disable
• Press Save to save the configuration in permanent memory
