TSA-200 / TSA-200XT / TSA-240 / TSA-240XT

Page 52 of 79

14.10 Test State

Test states allow testing the Control and Indicating Equipment (CIE) without activating

outputs. This state is indicated by the Test and Fault LEDs.

See Field Test, page 62, for additional information.
