TSA-200 / TSA-200XT / TSA-240 / TSA-240XT
© 2010 – 2014 Telefire Fire & Gas Detectors Ltd Revision 1.06 July 2014
Page 61 of 79
Press Select until the Alarm LED in the Zone 2 display area will flash.
Press Enable/Disable to remove Zone 2 from the activation conditions. Press
Enable/Disable again to include Zone 2 in the activation conditions.
If both zones are included in the extinguishing activation, extinguishing will be activated
only when both zones are in alarm at the same time. If only a single zone is included in
the extinguishing activation, extinguishing will be activated only by that zone.
16.10.3 Disabling/Enabling the Extinguishing Module
To disable the extinguishing module enter programming mode by pressing Menu and
key-in the password (default: 2222). Press Menu repeatedly to get to the disablement
menu. Press Select repeatedly to access the Extinguishing Module. Press
Enable/Disable to disable/enable the extinguishing module.
16.11 Saving Data and Exiting the Programming Mode
Press Save to save the configuration in permanent memory
The system stores configuration programming permanently, even when both primary
and secondary power sources are disconnected.
16.12 Recording Programmed Timing Values
After setting the timing values, (default or programmed), write down the Extinguishing
Delay Time and the Extinguishing Pulse Duration values by a non water soluble
(but Alcohol soluble) marker in the allocated spaces in the label attached to the
inside of the TSA-200 product family door.
Erase and write down updated values when they are programmed and or modified.
