TSA-200 / TSA-200XT / TSA-240 / TSA-240XT

Page 69 of 79

22 Standards compliance and approvals

Telefire’s TSA-200 product family have the following certification and approvals:

• EN 54-2 and EN 54-4 certified

• CE Marked

• UL 864 edition 9 compatible

• GOST 53325-2009 certified

22.1 CE Label

The TSA-200/200XT is CE marked.

The CE label is shown below.

It is attached to the outside of the box (per EN-54-2) on the left side

Do not remove the label.

Figure 28 TSA-200 product family CE label
