TSA-200 / TSA-200XT / TSA-240 / TSA-240XT
© 2010 – 2014 Telefire Fire & Gas Detectors Ltd Revision 1.06 July 2014
– Page 14 of 53 –
ITEM RATING REMARKS COMMUNICATION
PARAMETERS
Battery Charge Current, CP in
Alarm
No current Charging is disabled in Alarm
Battery Fuse PTC, 3A Self Resettable
Current consumption from battery 60mA Quiescent condition, buzzer ON Control Panel (CP) Only
Current consumption (TSA-200XT /
TSA-240 / TSA-240XT)
110mA, two zones in alarm CP Only, extinguisher OFF
Current consumption(TSA-200XT /
TSA-240 / TSA-240XT)
160mA, two zones in alarm, CP Only, extinguisher ON
Max Current from Batteries 3A Limited by PTC
Battery voltage range 20.4V DC min to 27.8V DC max
Max (single) battery size to 9.5 (W) by 7 (D) by 12.5 (H) cm each
MB INTERFACES
Fire Alarm Relay (1) contacts rating 48V DC, 1.5A, not monitored Dry contact SPDT
Fault Relay (2) contacts rating 48V DC, 1.5A, not monitored Dry contact SPDT NC when unpowered
OUTPUTS MB outputs are monitored
Outputs EOL 3.9 K ±5% Only required for MB outputs
