TSA-200 / TSA-200XT / TSA-240 / TSA-240XT
© 2010 – 2014 Telefire Fire & Gas Detectors Ltd Revision 1.06 July 2014
– Page 16 of 53 –
ITEM RATING REMARKS COMMUNICATION
PARAMETERS
Input Open threshold 7.5 kΩ to ∞
Inputs 1-2, Detection zones See above for inputs characteristics Detectors /MCP
KEYBOARD Input, "Manual Only"
Password protected
EM1 extinguishing Module inputs
See above for inputs characteristics EM1 card Inputs are monitored
Input 3 Pressure Switch See above for inputs characteristics
Input 4 Manual Activation See above for inputs characteristics
Input 5 Hold/Abort See above for inputs characteristics Inhibit, PC Programmable
EM1 Extinguishing Module
outputs
EM1 out 3, Extinguisher Level Act. 24V DC, 1.0 A for 20 seconds 0.5 A continuous (Solenoid) Switched DC
EM1 Ver. 1.1, out 3, Extinguisher Change Polarity, 1.0 A max OFF-6V. ON +24V 1.0 A continuous (Solenoid) Reversed Polarity DC
Extinguisher release delay 30 Seconds Default
Extinguisher release duration 20 Seconds Default
EM1 out 4,
Extinguishing/Evacuation Sounder
Level Act. 24V DC, 0.5A max, continuous Flashes in Activated state. ON
in Released state,
Modulated DC
